The SMEG DWAFI6224-4 Fully-Integrated Built-In Dishwasher brings Italian engineering into your kitchen with precision, style, and efficiency. Designed under the Universal aesthetic, this 60cm dishwasher fits seamlessly behind cabinetry, providing a sleek, integrated appearance that complements modern kitchens.
At the core of its performance is the Orbital Wash System, which uses dual rotating spray arms to ensure even water distribution and deep cleaning of every item in the load. The Dry Assist+ system enhances energy efficiency by automatically opening the door at the end of the cycle to accelerate and improve drying results without manual intervention.
This dishwasher features 10+1 versatile wash programs, including a rapid 27-minute cycle for quick cleaning, a high-temperature Ultraclean setting for hygienic sanitation, and a dedicated Crystals program for fragile glassware. The FlexiZone option allows for half loads in any configuration, conserving water and power while maintaining full washing performance.
User-friendly controls, delay start up to 24 hours, and an acoustic end-of-cycle signal ensure effortless operation. Inside, stainless steel tubs and filters offer durability, while two grey baskets with adjustable heights and anti-drip inserts accommodate up to 13 place settings.
Safety and reliability are enhanced with the Total Acquastop flood protection system, which immediately cuts off water in case of leaks. Designed to run quietly, with a noise level of just 48 dB(A), the DWAFI6224-4 delivers robust cleaning power with minimal disruption to your home environment.
At the core of its performance is the Orbital Wash System, which uses dual rotating spray arms to ensure even water distribution and deep cleaning of every item in the load. The Dry Assist+ system enhances energy efficiency by automatically opening the door at the end of the cycle to accelerate and improve drying results without manual intervention.
This dishwasher features 10+1 versatile wash programs, including a rapid 27-minute cycle for quick cleaning, a high-temperature Ultraclean setting for hygienic sanitation, and a dedicated Crystals program for fragile glassware. The FlexiZone option allows for half loads in any configuration, conserving water and power while maintaining full washing performance.
User-friendly controls, delay start up to 24 hours, and an acoustic end-of-cycle signal ensure effortless operation. Inside, stainless steel tubs and filters offer durability, while two grey baskets with adjustable heights and anti-drip inserts accommodate up to 13 place settings.
Safety and reliability are enhanced with the Total Acquastop flood protection system, which immediately cuts off water in case of leaks. Designed to run quietly, with a noise level of just 48 dB(A), the DWAFI6224-4 delivers robust cleaning power with minimal disruption to your home environment.
Anti-Drip Inserts
Blue anti-drip inserts are installed in the lower basket of Smeg's new generation dishwashers. This addition improves drying results and cuts down drips between dish and basket.
All the Hygiene Needed
The 99.9% Hygiene certified program responds to every washing need, allowing you to sterilize dishes at 75 °C and perfectly sanitize them even for children or allergy sufferers.
27 Minute Cleaning
Designed especially for lightly soiled dishes to be washed immediately after use, the Express 27' program only takes 27 minutes for a thorough cleaning.
Adjustable Rack
The flexibility of the upper basket offers three adjustable height options. This adaptability ensures that every type of dish, from tall glasses to oversized pots and delicate stemware, receives optimal cleaning and hygiene.
Specifications & Manuals
Key Specifications
| Dishwasher type | Fully Integrated |
|---|---|
| Model Number | DWAFI6224-4 |
| Weight (kg) | 41 kg |
| Depth (mm) | 570 mm |
| Height (mm) | 818 mm |
| Width (mm) | 598 mm |
| Power (W) | 1800 W |
| Accessories included | 1 x 1560mm Drain Outlet Hose |
| Can accommodate large dishes | |
| Capacity Place Settings | 14 |
| Finish Colour | Integrated (Own Cabinetry) |
| Notes | Custom-made fascia Door Panel required Supplied by your Kitchen Company or Builder. |
| Removable Lid | |
| Finish Colour Description | Silver Cabinet Requires a Custom Made Door Panel Provided by your Builder/Kitchen company. |
| Installation Note | Built Under your Kitchen Cabinet Installation. |
Other Features
| Water Inlets | Cold Only |
|---|---|
| Features | Installation Type: Built Under Installation Finish: Fully Integrated, Custom Fascia Door Panel Required, Supplied by your Builder/Kitchen Company. Controls: Electronic Control Panel. Drying System: Natural condenser drying, with Dry Assist + automatic door opening system at the end of the cycle. Water Connection: 1 x Single hose; cold or hot connection water max rating. 60°C. Flood Protection: Total Acquastop. End-of-Cycle Indicator: Led on display, with an acoustic signal. Plate Size: Lower rack 30cm, Upper rack 19cm. Extra Features: Orbital washing, Rinse aid Indicator, Concealed Heating element, Half Load Option. Wash Programs: |
| Height Adjustable Upper Basket | |
| Control type | Electronic Press Button |
| Cutlery Drawer | |
| Display Panel | LED |
| Temperature Control | Electronic |
| Time delay | |
| Cutlery basket |
Warranty
| Manufacturer Warranty | 5 Years |
|---|---|
| Use | Not intended or designed for commercial use. |
Energy Efficiency
| Energy Star Rating |  4 Stars |
|---|---|
| Energy Consumption(kWh/annum) | 230 |
Electrical Connection
| Type of connection | 10A plug & lead |
|---|---|
| Connected load | 1.8 kW |
| Connection requirements | This product requires a 10amp electrical connection. For more information, please contact Winning Services on 1300 020 020 or your electrician. |
| Maximum current rating | 7.5 A |
| Length of cord | 1.4 m |
Safety Features
| Child lock | |
|---|---|
| Overflow Protection | |
| Fault Indicator |
Smart Features
| Delay Start | |
|---|---|
| Time Remaining Display |
Programs
| Soak | |
|---|---|
| Number of Programs | 11 Programs |
| Quick wash | |
| Delicate | |
| Half load option | |
| Mixed | |
| Hygiene Wash |
Water Efficiency
| Litres Used Per Wash | 11.3 L |
|---|---|
| Water Star Rating |  5 Stars |
| Litres Per Cycle | 11.3 Ltr/Cycle |
| WELS Product Registration Number | D02955 |
Noise Level
| Noise when working | 49 dB |
|---|
Country of Origin
| Origin | Italy |
|---|
Connectivity
| WiFi |
|---|
Functions
| Eco Mode |
|---|
Other
| Filtration | 5 Stage Stainless Steel Filter System |
|---|---|
| Lid Included | |
| Primary Product Category | Integrated Dishwashers |
| Water consumption | 11.3 L |
| Big dish friendly | |
| Rinse aid light Notification | |
| End of Wash Alarm | |
| Dishwasher Compartments (Foldable Bottom Racks) | |
| Dishwasher Compartments (Foldable Cup Shelves) | |
| Tall Glass Rack | |
| Dishdrawer | |
| Custom Installation | |
| Fast Wash Option | |
| EAN | 8017709344047 |
| Eco Program | |
| Detachable lid |
