The Whispair London 90 wall canopy rangehood is ideal for cooking surfaces 75cm to 100cm in width.
The three-flare design incorporates Whispair’s exclusive S-Flow ‘commercial-grade’ baffle filtration system that maximises extraction performance and minimises operational noise all whilst filtering the airflow, removing up to 95% of the grease and moisture from the airflow.
The stainless-steel filters can be simply washed with soapy water or popped into a dishwasher.
The three-flare design incorporates Whispair’s exclusive S-Flow ‘commercial-grade’ baffle filtration system that maximises extraction performance and minimises operational noise all whilst filtering the airflow, removing up to 95% of the grease and moisture from the airflow.
The stainless-steel filters can be simply washed with soapy water or popped into a dishwasher.
Specifications & Manuals
Key Specifications
| Rangehood Type | Canopy |
|---|---|
| Model Number | X5L09S5.IP |
| Depth (mm) | 500 mm |
| Height (mm) | 880 mm |
| Width (mm) | 900 mm |
| Accessories included | 3 x Baffle Filters, 2 x Stainless Steel Flues Pieces, 5 Mtrs 200mm Acoustic Flexi Ducting. |
| Finish Colour | Stainless Steel |
| Notes | Wall Mounted Rangehood with Remote Inline Pro Motor. |
| Finish Colour Description | Stainless Steel Body. |
| Rangehood Model Number | X5L09S5.IP |
Warranty
| Manufacturer Warranty | 5 Years |
|---|---|
| Warranty Note | 5-Year Domestic Warranty on all Parts & Labour.
|
| Use | Not intended or designed for commercial use. |
Air Extraction
| Max Air Capacity | 1140 m³/h |
|---|---|
| Number of fan speeds | 4 |
| Ducting size | 200 |
| Ducting location | Top and rear |
Other Features
| Features | ● Suits 75cm - 100cm Cooking Surfaces ● Filters: S-Flow Baffl e Filters 3x (H-25) - Dishwasher Safe ● Lighting: LED 5x (1.0W) ● Finish: AISI304 1.0mm High Grade Stainless Steel ● Controls: LED Backlit 4 Button mastermind Electronic Control with LED Speed Indicator ● Speed Settings: 3 Speed + Boost Mode ● Programmable Timer (10min Increments) ● Auto Shut Off After 2Hrs Of Inactivity ● KleenAir Pro Remote Fan Solution - 1140 m3/hr |
|---|---|
| Super fast air extraction | |
| Programmable timer | |
| Control type | Electronic Press Button |
| Light type | LED |
| Motor Type | Inline Remote Motor |
| Boost function |
Electrical Connection
| Type of connection | 10A plug & lead |
|---|---|
| Connection requirements | This product requires a 10amp electrical connection. For more information, please contact Winning Services on 1300 020 020 or your electrician. |
| Maximum current rating | 10 A |
| Length of cord | 1.5 m |
Safety Features
| Automatic power off |
|---|
Filters
| Filter material | Baffle |
|---|---|
| Number of filters | 3 |
| Dishwasher safe filters |
Noise Level
| Noise when working | 49.6 dB |
|---|
Country of Origin
| Origin | Australia Built / German Motor System.
|
|---|
Other
| Primary Product Category | Rangehood |
|---|---|
| Dishwasher safe parts | |
| Filter | Yes |
| Stainless Steel Grade | 304 |
| EAN | 0784927560037 |
