With ActiveVent technology for optimised moisture levels and AeroTech for even heat distribution, you'll get perfect results even when using multiple shelves.

Cook With Confidence The intuitive 5" touchscreen lets you cook your way, by method, ingredient, function, or recipe. It guides you step-by-step or automatically adjusts heat and temperature based on your selection, ensuring confident, stress-free cooking every time you use your oven.

Designed to fit seamlessly into your kitchen, this built-in oven features premium materials and detailing to support a cohesive, considered kitchen design.

The CoolTouch door features triple glazing and a cooling system that ensures it’s safe to touch from the outside, protecting both your hands and the surrounding cabinetry.
| Model Number | OB76DDPTDX2 |
|---|---|
| Weight (kg) | 186 kg |
| Depth (mm) | 610 mm |
| Height (mm) | 1232 mm |
| Width (mm) | 760 mm |
| Power (W) | 8500 W |
| Accessories included | 2 x Flat brushed baking tray |
| Finish Colour | Black |
| Notes | *Depth of oven with front and control panel (excl. handle and dials): 650mm |
| Volume - Double Compartment Main (Net) | 102 |
| Volume - Double Compartment Second (Net) | 102 |
| Oven Fuel Type | Electric |
| Finish Colour Description | Black Fascia with Stainless Steel Accents. |
| Interior finish | Enamel |
| Manufacturer Warranty | 2 Years |
|---|---|
| Use | Not intended or designed for commercial use. |
| Features |
|
|---|---|
| Number of shelf positions | 5 |
| Programmable timer | |
| Control type | Control Knobs and Touch Control |
| Grill location | Integrated electric grill |
| Light type | Halogen |
| Internal oven light | |
| Portable | |
| Temperature Range - Maximum | 280 °C |
| Temperature Range - Minimum | 35 °C |
| Timer | |
| Number of shelves | 2 |
| Cooling fan | |
| Pyrolytic self cleaning | |
| Oven Type | Double Oven |
| Timer Functions | Clock / Timer |
| Easy clean cooking surface | |
| Meat probe |
| Cut Out Note | Wall mounted installation only. |
|---|
| Number of Functions | 17 |
|---|---|
| Fan bake | |
| Full grill | |
| Dehydrate | |
| Fan forced | |
| Keep warm | |
| Bake | |
| Roast | |
| Pizza | |
| Pyrolytic | |
| Fan grill | |
| Maxi grill | |
| Pastry bake | |
| Air Frying | |
| Classic bake | |
| Vent Bake | |
| Slow cooking |
| Type of connection | Hardwired |
|---|---|
| Connected load | 8.5 kW |
| Connection requirements | Needs to be hardwired by a qualified electrician |
| Maximum current rating | 35.5 A |
| Delay Start |
|---|
| Display |
|---|
| Oven Volume | 230 L |
|---|---|
| Volume Note | Gross volumes quoted |
| Triple glazed door |
|---|
| A true family size oven | |
|---|---|
| Primary Product Category | Pyrolytic Ovens |
| Oven Timer | |
| Volume - One Compartment (Net) | 204 |
| Multi Function | |
| Fan oven | |
| Oven Functions | MultiFunction |
| EAN | 9415112827703 |
| Proofing |
