Specifications & Manuals
Key Specifications
| Cooktop Type | Gas burners |
|---|---|
| Cooktop Fuel Type | Natural Gas |
| Model Number | AFGE5440W |
| Depth (mm) | 600 mm |
| Height (mm) | 900 mm |
| Width (mm) | 540 mm |
| Accessories included | 1 x Baking Tray, 1 x Grill Rack, 1 x Chrome Side Rack Supporta, 1x LP Gas Conversion Kit Included. |
| Cooktop Material | Enamel |
| Finish Colour | White |
| Notes | ** If Using the Mini Splashback Please add an extra 60mm to the overall height.** |
| Oven Fuel Type | Electric |
| Finish Colour Description | White Cabinet / See Through Oven Door Panel. |
Burners
| Number of cooktop Burners or Zones | 4 |
|---|---|
| Burner Material | Aluminium |
| Number of cooking zones | 4 |
| Ignition | Electronic |
| Trivets | Enamel |
| Wok burner |
Warranty
| Manufacturer Warranty | 2 Years |
|---|---|
| Warranty Note | Additional 3 years warranty available via redemption. |
| Use | Not intended or designed for commercial use. |
Other Features
| Features | Oven Features ● 4 functions — light, bottom element, top and bottom element, grill ● 5 shelf heights ● Single light ● Thermostat 50–250°C ● Removable door, double glazing ● Adjustable feet ● Standard inclusions: baking tray, grill rack, chrome side rack supports, heat-resistant tray handles Cooktop Features ● Four gas burners ● Wok 12.6Mj ● Auxiliary 3.6Mj ● Flame failure device fitted to each burner ● 2 x semi rapid 6.3Mj each |
|---|---|
| Number of shelf positions | 5 |
| Programmable timer | |
| Control type | Control knobs |
| Grill location | Integrated electric grill |
| Light type | Incandescent |
| Internal oven light | |
| Temperature Range - Maximum | 250 °C |
| Temperature Range - Minimum | 50 °C |
| Timer | |
| Cooling fan | |
| Pyrolytic self cleaning | |
| Oven Type | Upright Oven/Stove |
| Easy clean cooking surface | |
| Cooktop Configuration | 3 Burners and Wok Burner |
Functions
| Number of Functions | 4 |
|---|---|
| Bottom heating | |
| Full grill | |
| Light | |
| Conventional |
Electrical Connection
| Type of connection | 10A plug & lead |
|---|---|
| Connected load | 2 kW |
| Connection requirements | This product requires a 10amp electrical connection. For more information, please contact Winning Services on 1300 020 020 or your electrician. |
| Maximum current rating | 10 A |
| Length of cord | 1.5 m |
Safety Features
| Child lock | |
|---|---|
| Triple glazed door | |
| Flame failure protection |
Display
| Display |
|---|
Country of Origin
| Origin | China |
|---|
Volume
| Oven Volume | 56 L |
|---|---|
| Volume Note | Gross volumes quoted |
(null)
| Freestanding Oven Installation Type | Dual Fuel |
|---|
Other
| Primary Product Category | Stove |
|---|---|
| Oven Timer | |
| Multi Function | |
| Steam Ovens | |
| Combination Microwave Ovens | |
| EAN | 9347777001313 |
| Dual Fuel | |
| Combination Steam Ovens |
